30" Gas Downdraft Cooktop KitchenAid KCGD500GSS

SKU: 0740204

$2 899.99

2 Special offer(s) available

close

How to benefit


Purchase options
  • Free delivery* Available between November 12 and November 17
  • Quebec Distribution Center
    Pick up not available See in store unavailable
Compare product
Wishlists Wishlists
Add to my wishlist
close

In-store availability


Description

Gas Cooking Power with Built-In Ventilation

The KitchenAid KCGD500GSS 30-inch gas cooktop combines the precision of four sealed burners with a downdraft ventilation system integrated directly into the cooking surface. This design provides a functional, open cooking area without requiring a traditional range hood above the countertop.

Featuring two professional burners rated at 17,000 and 15,000 BTU, a 5,000 BTU Even-Heat™ simmer burner, and a 300 CFM ventilation system, it offers the versatility needed for everything from high-heat cooking to delicate preparations.

300 CFM Downdraft Ventilation

The integrated ventilation system draws smoke, steam, and odours directly from the cooking surface, eliminating the need for an additional range hood. With a 300 CFM exhaust capacity, it provides ventilation for high-temperature cooking techniques such as searing meats and pan-frying.

The three-speed fan lets you adjust the ventilation power according to what you are preparing and the intensity of the cooking.

Ducted or Duct-Free Installation

The ventilation system can exhaust smoke and odours outdoors through ductwork. For kitchens where exterior venting is not possible, the cooktop can also be converted to recirculating operation using a duct-free conversion kit, sold separately.

This flexibility provides more options when planning your cooking space, particularly in kitchens where the layout limits the installation of a traditional range hood.

17,000 BTU Professional Burner for High-Heat Cooking

The 17,000 BTU professional burner delivers intense heat for searing meats, stir-frying, and wok cooking. Its power supports cooking techniques that require high temperatures while also offering lower settings for preparations that call for gentle simmering.

A second 15,000 BTU professional burner helps bring liquids to a boil quickly and allows you to prepare other foods at high temperatures at the same time.

Even-Heat™ Burner for Delicate Cooking

The 5,000 BTU Even-Heat™ simmer burner is designed to provide precise heat control at low temperatures. Its heat-diffusing plate helps distribute the flame more evenly at the lowest setting for gently simmering sauces and melting delicate ingredients.

The melt burner cap also helps diffuse gentler heat for melting chocolate or butter, preparing delicate sauces, or poaching eggs without exposing foods directly to excessive heat.

Electronic Ignition and Automatic Reignition

The electronic ignition system lights the burners with an electric spark, eliminating the need for a continuously burning pilot light. If a flame is accidentally extinguished, the automatic reignition system produces another spark to relight the affected burner.

This feature helps provide convenient and reliable operation while preparing meals.

Cast-Iron Grates and Durable Controls

Full-width cast-iron grates provide a stable, continuous surface for pots and pans. They make it easier to move cookware from one burner to another without having to lift it completely.

Stainless steel control knobs complement the cooktop’s design and make it easy to adjust the flame intensity of each burner.

Key Features

  • 30-inch gas cooktop
  • Four sealed burners
  • Integrated downdraft ventilation system
  • 300 CFM ventilation capacity
  • Three-speed fan
  • 17,000 BTU professional burner for high-heat cooking
  • 15,000 BTU professional burner for searing foods and quickly bringing liquids to a boil
  • 5,000 BTU Even-Heat™ simmer burner with heat-diffusing plate
  • Melt burner cap for delicate preparations
  • Electronic ignition with automatic reignition
  • Full-width cast-iron grates for easier movement of cookware
  • Stainless steel control knobs
  • Ventilation can be converted to recirculating operation with a duct-free kit, sold separately
  • Liquid propane conversion available with the included kit

Burner Configuration and Power

  • Professional burner: 17,000 BTU
  • Professional burner: 15,000 BTU
  • Standard burner: 10,000 BTU
  • Even-Heat™ simmer burner: 5,000 BTU

Technical Specifications

  • Model: KCGD500GSS
  • Appliance type: built-in gas cooktop with integrated ventilation
  • Nominal width: 30 in.
  • Number of burners: 4
  • Burner type: sealed
  • Maximum main burner output: 17,000 BTU
  • Ventilation type: downdraft
  • Maximum exhaust airflow: 300 CFM
  • Number of fan speeds: 3
  • Ignition type: electronic with automatic reignition
  • Control type: rotary knobs
  • Grate material: cast iron
  • Liquid propane conversion: yes, kit included
  • Electrical supply: 120 V
  • Amperage: 15 A

Dimensions

  • Width: 30 in.
  • Depth: 21 1/2 in.
  • Overall height: 18 7/16 in.

Please note: The conversion kit for duct-free installation is sold separately. Cutout dimensions and required clearances for the ventilation system should be verified in the manufacturer’s installation guide before preparing the countertop and cabinetry.

Manufacturer's plan

Specifications
Others
  • Cooktop Type : Gaz
  • Cooktop Width : 30-inch wide
  • Integrated ventilation : No
Finish
  • Outer finish : Stainless Steel
  • Secondary finish : Black
Elements/burners
  • Number of elements/burners : N/D
  • Cooktop Type : Sealed burners
  • Gas type : N/D
  • Convertible liquid propane/natural gas : Yes
  • Expandable element : No
  • Right Front Element Burner Power : 10 000 BTUW
  • Left Front Element Burner Power : 17 000 BTUW
  • Right Rear Element Burner Power : 15 000 BTUW
  • Left Rear Element Burner Power : 5 000 BTUW
Miscellaneous/features
  • Control Panel Type : Mechanical
Dimensions
Unpacked (in Inches)
  • Length : 30
  • Depth : 22
  • Height : 18 1/2

Approximate size. For more information, please contact our customer service.
